Technical data: |
OJ-008 |
|
With Generator Set |
|
|
Applicable Rim |
13"-26" |
|
Max. wheel diameter |
1300mm |
|
Max. wheel width |
600mm |
|
Bead breaker force
|
2500kg |
|
Max. wheel weight |
700kg |
|
Motor power |
2.2ke,2-speed Motor with CW and CCW |
|
Hydraulic pump motor: Gearbox motor: |
1.1Kw |
|
Min. Height of Machines Chassis to the Top of the Door: |
1450mm |
|
Min. Width of Inner Van |
1650mm |
|
Min Width of Door |
980mm
|
|
Thick of Van |
≤160mm
|
|
Chassis of the Van to Floor
|
≈700mm |
|
Power supply |
220/380V/400V 50/60hz 1p/3p |
|
Operation pressure |
0-130bar |
|
Net weight |
650Kg |
|
Packing outside dimension |
1180*1000*1550mm 1160*1000*1550mm 1700*1100*1650mm
|
