Standard Features:
1. Automatic Electric release Lock.
2.Door Opening protection rubber avoid damages.
3. Limited witch for max height automatic stop.
4.Two steps columns install.
5.Optional 3 steps arm design in suitable for different length adjustment.
6.Optional foot protection design on arms .
7.Optional electric control box operation .
|
Standard Features |
SDL-4000E |
|
Lifting Capacity |
4000kg/5000kg |
|
Maximum Lifting Height |
1900mm |
|
Minimum Height |
105mm |
|
Column Height |
3880mm |
|
Rated Voltage |
220V/380V |
|
Net Weight |
815Kg |
|
Gross Weight |
850Kg |
|
Column Width |
2910mm |
|
Packing Size |
3900*520*750mm 820*340*360mm |
